Advanced Light Microscopy Unit
Advanced Light Microscopy Unit
The Advanced Light Microscopy Unit (ALMU) is a walk-in core unit on a mission to help, support and educate the research community from CRG and beyond to do quantitative bioimaging. We provide support on a range of technologies starting from experimental design, sample preparation, acquisition, bioimage analysis and visualization.
Our unit consists of microscope systems specifically designed for fluorescence microscopy ranging from widefield, and confocal to super-resolution systems and helps reveal structures from macro to the nanoscale. Together with our next-door neighbors, the Mesoscopic Imaging Facility (MIF) of the EMBL Barcelona, we cover the full spectrum of light microscopy and we collaborate to assist the scientific community in advancing their research. Click on the services tab to learn more about our support and how to gain access to our instruments.
You can learn more about the unit by taking the virtual tour HERE.
|OMERO Workshop (7-8/11/2024)
ALMU together with OME, the University of Dundee, and CRG's SIT & CRG training are organizing the OMERO workshop. This course will give a solid ground for CRG researchers and all researchers who would like to use the open-source image data management software to enable access, analysis, visualization, sharing, and publishing of microscopy data. This course is also an important milestone for CRG to start using CRG's OMERO server for image data management. For more information follow the link here.
|Spotlight on Jeremy Vincencio, Shoma Nakagawa & ALMU in Evident's innovative laser scanning confocal system brochure
We are proud to see the fruit of our successful collaboration with Evident and ALMU users: Jeremy Vincencio's (Stroustrup Lab) and Shoma Nakagawa (Cosma Lab) in the brochure of Evident's new innovative laser scanning confocal system FLUOVIEW FV4000. Tests on the prototype were carried out at ALMU. For more information follow the link here.
|ALMU collaborates with a global initiative to promote reproducible microscopy data publishing (21/09/2023)|
|ALMU collaborates to reveal the ancient origins of neurons (19/09/2023)|
ALMU collaborates to test the new function Dynamic Profiler from Carl Zeiss
We are proud to see the successful launch of the new function Dynamic Profiler which enables the measurement of molecular dynamics with spatial information. Tests were carried out at ALMU, with ALMU and ALMU users. For more information follow the link here.
Elyra 7 with Lattice SIM2 workshop with Carl Zeiss (27/03/2023)
ALMU hosted the Elyra 7 workshop that presents the latest advances allowing gentle imaging of cellular structure in the nanoscale, using SIM, PALM/STORM technologies at high speed with the ability to image deeper into the samples.
February 27: Virtual seminar covering the ELyra 7 system capabilities and highlighting the super-resolution technology. Followed by a virtual live demo of the system.
February 27 - March 3: Hands-on demo with researcher's own samples.
Quantitative Light Microscopy Course (20-24/02/2023)
IXplore SpinSR workshop with Evident/Olympus (04/05/2022)
ALMU hosted the IXplore SpinSR workshop that presented the latest advances in multi-modal confocal spinning disk imaging of live cells and tissues in super-resolution mode.
May 4: Virtual seminar covering the IXplore SpinSR system capabilities and highlighting the super-resolution technology. Followed by a virtual live demo of the system.
May 5 - May 18: Hands-on demo with researcher’s own samples.
CRG at the Dubai Expo Spain Pavilion (03/2022)
Nadia Halidi has joined forces with Neoalgae, an Austrian biotechnology company, and The Others TV, an animation studio based in Barcelona to showcase the potential of microalgae as a sustainable future solution. The movies were acquired with a high-speed camera using darkfield microscopy with components provided specifically for this project by Carl Zeiss Iberia S.L. The production was showcased in the Spain Pavilion at the Expo 2020 Dubai from October 2021 to March 2022.
Nadia Halidi CV
February 2021 Head of the Advanced Light Microscopy Unit, CRG, Barcelona, Spain.
2018 - 2021 Assistant manager, then manager of Micron Oxford Advanced Bioimaging Unit, University of Oxford, Oxford, UK.
2017 - 2018 Postdoctoral researcher and imaging facility manager at the Botnar Research Center, University of Oxford, Oxford, UK.
2011 - 2015 Postdoctoral fellow at the Dept. of Cell Biology, Harvard Medical School, Boston, MA, USA.
2007 - 2011 PhD in Biophysics, École Polytechnique Fédérale de Lausanne (EPFL), Lausanne, Switzerland.
2005 Teaching assistant at the Kalamazoo College, Kalamazoo, MI, USA.
2002 - 2006 Research and teaching assistant at the Dept. of Biophysics, University of Pécs, Pécs, Hungary.
The equipment offer is available to trained users and covers all current imaging applications with high-end imaging systems.
- Leica confocal STED 3X FALCON system with white light laser (WLL) and three depletion wavelengths (WLL: 470 - 670 nm, 592nm CW, 660nm CW, 775nm pulsed)
- Nikon N-STORM (405nm, 488nm, 561nm, 647 nm lasers)
- Zeiss LSM 980 with airyscan 2 (405, 488, 561, 639 nm lasers)
- Leica confocal CW STED super-resolution microscope with 592 nm CW depletion wavelength
- Leica Ground State Depletion (GSD) microscope system (488 nm, 532 nm, 647 nm, 405 nm backpumping)
- Leica inverted confocal/multiphoton system (405, Argon ion, 561, 633nm and Mai Tai DeepSee)
- Leica upright confocal/multiphoton system (405, Argon ion, 543, 633nm and Mai Tai DeepSee)
- Leica STELLAIRS confocal system with white light laser ( WLL: 485 - 685, also 405, 488, 561 nm lasers)
- Leica inverted confocal system (405, 458,476,488,496,514,561 and 633 nm lasers)
- Leica inverted confocal system for live-cell imaging (458,476,488,514,543 and 633 nm lasers)
- Zeiss Cell Observer fluorescence microscope for live-cell imaging
- Olympus MVX10 Macro Zoom fluorescence microscope
- Molecular Devices ImageXpress Micro Purchase year: 2009
- AQUIFER HIVE for image processing and analysis
- 2 workstations for image processing
Workstations and Software packages
- Analysis workstations and AQUIFER HIVE for image processing and analysis
- Open source software: ImageJ/Fiji, Cel Profiler, Advanced Cell Classifier
- SVI Huygens Deconvolution software
- Bitplane Imaris 3D and 4D imaging software
